CAMERA
Image sensor: 1/1.8-inch Sony 4K CMOS
Effective pixels: 8.29 million pixels
Resolutions and frame rates: 3840x2160p60/59/50/30/29.97/25 (HDMI/12G-SDI/SFP+/LAN) | 1920x1080p60/59/50/30/29.97/25 (HDMI/12G-SDI/3G-SDI/SFP+/LAN) | 1920x1080i60/59/50 (HDMI/12G-SDI/3G-SDI/SFP+/LAN) | 1280x720p60/59/50 (HDMI/12G-SDI/3G-SDI/SFP+/LAN)
Zoom: Optical: 25x | Digital: 16x
Focal length: 7.10 mm ~ 171.95 mm | 0.28 in. ~ 6.77 in.
Horizontal field of view: 59.2° ~ 2.5°
Minimum distance to the object: 0.3 m | 1 foot
Opening: F1.61 ~ F5.19
Focus Mode: Automatic, manual
Exposure mode: Auto, Manual, Shutter Priority, Aperture Priority (Iris)
Shutter speed: 1/60 s - 1/10,000 s
Minimum illumination: 0.1 lux (f/1.8, AGC enabled)
SNR: > 50 dB
DNR: 2D, 3D
PTZ MOTION
Horizontal/Vertical Rotation (Pan/Tilt): Horizontal: -174° to +174°, Vertical: -30° to +90°
Horizontal/vertical rotation speed: Horizontal: 0.1°/s to 35°/s, Vertical: 0.1°/s to 30°/s
Number of preset positions: Up to 255 (10 via remote control)
AI FEATURES
Tracking modes: Presenter Tracking, Zone Tracking (8 zones), Hybrid Tracking (8 zones), Auto Framing
Selecting a target by clicking: Supported (via the web interface only)
Privacy mask: Supported (via the web interface only) (applies to all captured faces)
Gesture control: 5 gestures (turn tracking on/off, change target, zoom in/out)
I/O INTERFACE
Video output interface: 12G-SDI (BNC), 3G-SDI (BNC), HDMI (HDMI Type A), SFP+ (compatible with SFP28 transceivers*—see the SFP+ Module Compatibility Guide for more details), LAN (RJ45)
Video compression formats: H.264, H.265
audio interface: 1 line input (3.5 mm TRS / 1/8'')
audio compression formats: AAC
Network interface: RJ45 (10/100/1000 Mbps Ethernet port) Control interface: RS-232 (input/output), RS-422, RS-485 Protocols: RTSP, RTMP, RTMPS, SRT, NDI®|HX2/3, FreeD, ONVIF, VISCA, VISCA IP, Pelco-D, Pelco-P Genlock and Timecode: Compatible
GENERAL
Certifications FCC, CE, RoHS
Power Requirements: DC 12 V±10% or PoE+
Power Consumption: < 18 W
Operating Temperature: -10°C ~ +50°C | 14°F ~ 122°F
Operating Humidity: 20%–80%
Dimensions (L x W x H): 193 x 158 x 208 mm | 7.60 x 6.22 x 8.19 in
Weight: 1.9 kg | 4.19 lb
Tally Light: Supported
Web Access: Integrated Laia UI
Included Accessories: Power Supply IR Remote Control User Manual (QR) RS232 Control Cable
Warranty: 3 years of Prime Support Service* (*Extendable to 6 years upon registration)
